15000(ZH)連接器

■技術(shù)參數(shù)(SPECIFICATIONS)

口線數(shù)(Poles):2~13

口適用線規(guī)(Applicable wires):AWG32#~26#

口適用基板厚度(Applicable PC board thickness):1.2mm

口溫度范圍(Temperature range):-25℃~85℃

口額定電壓(Voltage rating):50V.AC/DC

口額定電流(Current rating):1A

口接觸電阻(Contact resistance):≤0.02Ω

口絕緣電阻(Insulation resistance):≥500MΩ

口耐壓(Withstand voltage):500V.AC/1min

口材料(Material):

口孔座(Houshing):尼龍(PA66)UL94V-2(0)

口針座(Wafer):尼龍(PA66)/PA6T/PA9T UL94V-2(0)

口端子(Terminal):磷青銅

口包裝方式(Package):貼片(Wafer)

□P:散裝(Loosen Package)

□T:管裝(Pipe Package)

□R:編帶(Tape And Reel Package)
